Optoaisladores - Salida de transistor, fotovoltaica
| Foto: | Número de parte del fabricante | Disponibilidad | Precio | Cantidad | Ficha técnica | Packaging | Series | ProductStatus | NumberofChannels | Voltage-Isolation | CurrentTransferRatio(Min) | CurrentTransferRatio(Max) | TurnOn/TurnOffTime(Typ) | Rise/FallTime(Typ) | InputType | OutputType | Voltage-Output(Max) | Current-Output/Channel | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | VceSaturation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HCPL-2531-300EOPTOISO 3.75KV 2CH TRANS 8DIPGW Broadcom Limited |
161 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 2 | 3750Vrms | 19% @ 16mA | 50% @ 16mA | 200ns, 600ns | - | DC | Transistor | 20V | 8mA | 1.5V | 25 mA | - | -55°C ~ 100°C | Surface Mount |
|
HCPL-073A-500EOPTOISO 3.75KV 2CH DARLNG 8-SO Broadcom Limited |
3,591 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 2 | 3750Vrms | 600% @ 500µA | 8000% @ 500µA | 3µs, 34µs | - | DC | Darlington | 18V | 60mA | 1.25V | 5 mA | - | 0°C ~ 70°C | Surface Mount |
|
HCPL-2731-000EOPTOISO 3.75KV 2CH DARLNG 8-DIP Broadcom Limited |
3,590 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 2 | 3750Vrms | 500% @ 1.6mA | 2600% @ 1.6mA | 5µs, 10µs | - | DC | Darlington | 18V | 60mA | 1.4V | 12 mA | 100mV | 0°C ~ 70°C | Through Hole |
|
ACPL-M43T-000EOPTOISOLATOR 4KV TRANSISTOR 5-SO Broadcom Limited |
3,335 | - |
RFQ |
Ficha técnica |
Tube | Automotive, AEC-Q100, R²Coupler™ | Active | 1 | 4000Vrms | 32% @ 10mA | 100% @ 10mA | 150ns, 500ns | - | DC | Transistor | 20V | 8mA | 1.55V | 20 mA | - | -40°C ~ 125°C | Surface Mount |
|
|
HCPL-0370-000EOPTOISO 3.75KV DARLINGTON 8-SO Broadcom Limited |
3,928 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 1 | 3750Vrms | - | - | 4µs, 10µs | 20µs, 0.3µs | AC, DC | Darlington | 20V | 30mA | - | - | - | -40°C ~ 85°C | Surface Mount |
|
|
ACPL-054L-000EOPTOISOLTR 3.75KV 2CH TRANS 8-SO Broadcom Limited |
3,903 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 2 | 3750Vrms | 93% @ 3mA | 200% @ 3mA | 200ns, 380ns | - | DC | Transistor | 24V | 8mA | 1.5V | 20 mA | - | -40°C ~ 105°C | Surface Mount |
|
|
HCPL-0730-000EOPTOISO 3.75KV 2CH DARLNG 8-SO Broadcom Limited |
2,646 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 2 | 3750Vrms | 300% @ 1.6mA | 2600% @ 1.6mA | 5µs, 10µs | - | DC | Darlington | 7V | 60mA | 1.4V | 12 mA | 100mV | 0°C ~ 70°C | Surface Mount |
|
|
HCPL-073L-000EOPTOISO 3.75KV 2CH DARLNG 8-SO Broadcom Limited |
3,727 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 2 | 3750Vrms | 300% @ 1.6mA | 2600% @ 1.6mA | 25µs, 50µs | - | DC | Darlington | 7V | 60mA | 1.5V | 20 mA | - | 0°C ~ 70°C | Surface Mount |
|
|
HCNR201-300EOPTOISO 5KV LINEAR PHVOLT 8DIPGW Broadcom Limited |
2,314 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 1 | 5000Vrms | 0.36% @ 10mA | 0.72% @ 10mA | - | - | DC | Photovoltaic, Linearized | - | - | 1.6V | 25 mA | - | -55°C ~ 100°C | Surface Mount |
|
|
HCPL-3760-000EOPTOISO 3.75KV DARLINGTON 8-DIP Broadcom Limited |
868 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 1 | 3750Vrms | - | - | 4.5µs, 8µs | 14µs, 0.4µs | AC, DC | Darlington | 20V | 30mA | - | - | - | -40°C ~ 85°C | Through Hole |
.jpg)
|
HCNR201OPTOISO 5KV LINEAR PHVOLT 8DIP Broadcom Limited |
838 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 1 | 5000Vrms | 0.36% @ 10mA | 0.72% @ 10mA | - | - | DC | Photovoltaic, Linearized | - | - | 1.6V | 25 mA | - | -55°C ~ 100°C | Through Hole |
|
6N140A/883BOPTOISO 1.5KV 4CH DARLNG 16-DIP Broadcom Limited |
159 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 4 | 1500VDC | 200% @ 5mA | - | 2µs, 8µs | - | DC | Darlington | 20V | 40mA | 1.4V | 10 mA | 110mV | -55°C ~ 125°C | Through Hole |
|
|
8302401EAOPTOISO 1.5KV 4CH DARLNG 16-DIP Broadcom Limited |
259 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 4 | 1500VDC | 200% @ 5mA | - | 2µs, 8µs | - | DC | Darlington | 20V | 40mA | 1.4V | 10 mA | 110mV | -55°C ~ 125°C | Through Hole |
|
|
HCPL-5701OPTOISO 1.5KV DARLINGTON 8-DIP Broadcom Limited |
111 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 1 | 1500VDC | 200% @ 5mA | - | 2µs, 8µs | - | DC | Darlington | 20V | 40mA | 1.4V | 10 mA | 110mV | -55°C ~ 125°C | Through Hole |
|
HCPL-6750OPTOISO 1.5KV 4CH DARL 16FLATPAK Broadcom Limited |
2,299 | - |
RFQ |
Ficha técnica |
Tube | - | Active | 4 | 1500VDC | 200% @ 5mA | - | 2µs, 8µs | - | DC | Darlington | 20V | 40mA | 1.4V | 10 mA | 110mV | -55°C ~ 125°C | Surface Mount |
|
HCPL-817-50AEOPTOISOLATOR 5KV TRANSISTOR 4SMD Broadcom Limited |
2,061 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 5000Vrms | 80% @ 5mA | 160% @ 5mA | - | 4µs, 3µs | DC | Transistor | 70V | 50mA | 1.2V | 50 mA | 200mV | -30°C ~ 100°C | Surface Mount |
|
|
HCPL-817-56CEOPTOISOLATOR 5KV TRANSISTOR 4SMD Broadcom Limited |
3,971 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 5000Vrms | 200% @ 5mA | 400% @ 5mA | - | 4µs, 3µs | DC | Transistor | 70V | 50mA | 1.2V | 50 mA | 200mV | -30°C ~ 100°C | Surface Mount |
|
HCPL-181-06AEOPTOISO 3.75KV TRANS 4MINIFLAT Broadcom Limited |
2,068 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 3750Vrms | 80% @ 5mA | 160% @ 5mA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 50 mA | 200mV | -55°C ~ 100°C | Surface Mount |
|
4N25-500EOPTOISO 2.5KV TRANS W/BASE 6SMD Broadcom Limited |
2,464 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 2500Vrms | 20% @ 10mA | - | - | 3µs, 3µs | DC | Transistor with Base | 30V | 100mA | 1.2V | 80 mA | 500mV | -55°C ~ 100°C | Surface Mount |
|
|
ACPL-827-500EOPTOISOLATOR 5KV 2CH TRANS 8SMD Broadcom Limited |
2,455 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 2 | 5000Vrms | 50% @ 5mA | 600% @ 5mA | - | 4µs, 3µs | DC | Transistor | 70V | 50mA | 1.2V | 50 mA | 200mV | -30°C ~ 100°C | Surface Mount |
