Iluminación LED - COB, motores, módulos, tiras

Número de parte del fabricante	Disponibilidad	Precio	Cantidad	Ficha técnica	Packaging	Series	ProductStatus	Type	Color	CCT(K)	Wavelength	Configuration	LuminousFlux@Current/Temperature	Current-Test	Temperature-Test	Voltage-Forward(Vf)(Typ)	Lumens/Watt@Current-Test	Current-Max	CRI(ColorRenderingIndex)	ViewingAngle	Features	Size/Dimension	Height	LightEmittingSurface(LES)
BXRC-50G2001-D-74-SE VERO SE 13D COOL WHITE LED ARRAY Bridgelux	2,564	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Round	2046lm (Typ)	500mA	85°C	30.9V	132 lm/W	1A	90	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-57C2001-D-74-SE VERO SE 13D COOL WHITE LED ARRAY Bridgelux	3,437	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Cool	5700K 4-Step MacAdam Ellipse	-	Round	2476lm (Typ)	500mA	85°C	30.9V	160 lm/W	1A	70	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-57E2001-D-74-SE VERO SE 13D COOL WHITE LED ARRAY Bridgelux	3,496	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Cool	5700K 4-Step MacAdam Ellipse	-	Round	2375lm (Typ)	500mA	85°C	30.9V	154 lm/W	1A	80	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-65C2001-D-74-SE VERO SE 13D COOL WHITE LED ARRAY Bridgelux	3,166	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Cool	6500K 4-Step MacAdam Ellipse	-	Round	2519lm (Typ)	500mA	85°C	30.9V	163 lm/W	1A	70	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-65E2001-D-74-SE VERO SE 13D COOL WHITE LED ARRAY Bridgelux	3,342	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Cool	6500K 4-Step MacAdam Ellipse	-	Round	2418lm (Typ)	500mA	85°C	30.9V	156 lm/W	1A	80	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRE-40E2000-C-83 V13C NEUTRAL WHITE LED ARRAY Bridgelux	3,215	-	RFQ	Ficha técnica	Tube	V Series™ Gen 8	Active	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	3078lm (Typ)	500mA	25°C	33.4V	183 lm/W	-	80	-	-	-	-	13.00mm Dia
BXRE-30E3000-D-83 V15D WARM WHITE LED ARRAY Bridgelux	2,046	-	RFQ	Ficha técnica	Tube	V Series™ Gen 8	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	3010lm (Typ)	500mA	25°C	33.7V	178 lm/W	-	80	-	-	-	-	15.00mm Dia
BXRC-27H2000-B-73-SE LED COB VERO SE 2700K ROUND Bridgelux	3,793	-	RFQ	Ficha técnica	Tray	Décor Series™ Vero® SE 13	Active	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Round	1611lm (Typ)	450mA	85°C	34.1V	105 lm/W	900mA	97	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-30G200C-B-73-SE LED COB VERO 13 SE 3000K ROUND Bridgelux	2,870	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Round	1672lm (Typ)	450mA	85°C	34.1V	109 lm/W	900mA	90	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-27E2000-B-72-SE VERO SE 13B WARM WHITE LED ARRAY Bridgelux	2,970	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Warm	2700K 2-Step MacAdam Ellipse	-	Round	2128lm (Typ)	450mA	85°C	33.9V	139 lm/W	900mA	80	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-27G2000-B-72-SE VERO SE 13B WARM WHITE LED ARRAY Bridgelux	2,241	-	RFQ	Ficha técnica	Tray	Gen 7 Vero® 13 Array	Active	Chip On Board (COB)	White, Warm	2700K 2-Step MacAdam Ellipse	-	Round	1776lm (Typ)	450mA	85°C	33.9V	116 lm/W	900mA	90	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-30A2001-B-73-SE VERO SE 13B WARM WHITE LED ARRAY Bridgelux	2,295	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Round	1663lm (Typ)	450mA	85°C	33.9V	109 lm/W	900mA	93 (Typ)	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-30E2000-B-72-SE VERO SE 13B WARM WHITE LED ARRAY Bridgelux	2,752	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Warm	3000K 2-Step MacAdam Ellipse	-	Round	2213lm (Typ)	450mA	85°C	33.9V	145 lm/W	900mA	80	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-30G2000-B-72-SE VERO SE 13B WARM WHITE LED ARRAY Bridgelux	2,873	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Warm	3000K 2-Step MacAdam Ellipse	-	Round	1846lm (Typ)	450mA	85°C	33.9V	121 lm/W	900mA	90	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-30H2000-B-73-SE VERO SE 13B WARM WHITE LED ARRAY Bridgelux	2,112	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Round	1649lm (Typ)	450mA	85°C	33.9V	108 lm/W	900mA	97 (Typ)	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-35A2001-B-73-SE VERO SE 13B WARM WHITE LED ARRAY Bridgelux	3,939	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Warm	3500K 3-Step MacAdam Ellipse	-	Round	1790lm (Typ)	450mA	85°C	33.9V	117 lm/W	900mA	93 (Typ)	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-35E2000-B-72-SE VERO SE 13B WARM WHITE LED ARRAY Bridgelux	3,360	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Warm	3500K 2-Step MacAdam Ellipse	-	Round	2283lm (Typ)	450mA	85°C	33.9V	150 lm/W	900mA	80	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-35G2000-B-72-SE VERO SE 13B WARM WHITE LED ARRAY Bridgelux	2,981	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Warm	3500K 2-Step MacAdam Ellipse	-	Round	1903lm (Typ)	450mA	85°C	33.9V	125 lm/W	900mA	90	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-40A2001-B-73-SE VERO SE 13B NEUTRAL WHITE LED AR Bridgelux	2,826	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Round	1917lm (Typ)	450mA	85°C	33.9V	126 lm/W	900mA	93 (Typ)	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
BXRC-40E2000-B-72-SE VERO SE 13B NEUTRAL WHITE LED AR Bridgelux	3,188	-	RFQ	Ficha técnica	Tray	Vero® SE 13 Array	Active	Chip On Board (COB)	White, Neutral	4000K 2-Step MacAdam Ellipse	-	Round	2297lm (Typ)	450mA	85°C	33.9V	151 lm/W	900mA	80	120°	-	36.20mm Dia	3.60mm	13.40mm Dia
