Iluminación LED - COB, motores, módulos, tiras
| Foto: | Número de parte del fabricante | Disponibilidad | Precio | Cantidad | Ficha técnica | Packaging | Series | ProductStatus | Type | Color | CCT(K) | Wavelength | Configuration | LuminousFlux@Current/Temperature | Current-Test | Temperature-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | CRI(ColorRenderingIndex) | ViewingAngle | Features | Size/Dimension | Height | LightEmittingSurface(LES) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BXRC-40E10K0-L-02LED ARRAY 10000LM NEUTRAL WHITE Bridgelux |
2,650 | - |
RFQ |
Ficha técnica |
Tray | Vero® 29 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 10260lm (Typ) | 2.1A | 25°C | 38.6V | 127 lm/W | 4.2A | 80 | 120° | With Connector | 49.20mm Dia | 1.90mm | 29.20mm Dia |
|
BXRC-40E2000-C-02LED ARRAY 2000LM NEUTRAL WHITE Bridgelux |
2,675 | - |
RFQ |
Ficha técnica |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 2060lm (Typ) | 500mA | 25°C | 32.5V | 127 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia |
|
|
BXRC-40E2000-C-Z2LED ARRAY 2000LM NEUTRAL WHITE Bridgelux |
3,424 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 1822lm (Typ) | 500mA | 85°C | 31.5V | 116 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-40E2000-C-Z3LED ARRAY 2000LM NEUTRAL WHITE Bridgelux |
3,094 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 1822lm (Typ) | 500mA | 85°C | 31.5V | 116 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
BXRC-40E4000-F-02LED ARRAY 4000LM NEUTRAL WHITE Bridgelux |
3,199 | - |
RFQ |
Ficha técnica |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 3990lm (Typ) | 1.05A | 25°C | 29.5V | 129 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia |
|
|
BXRC-40E4000-F-Z2LED ARRAY 4000LM NEUTRAL WHITE Bridgelux |
2,711 | - |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 3511lm (Typ) | 1.05A | 85°C | 28.8V | 116 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-40E4000-F-Z3LED ARRAY 4000LM NEUTRAL WHITE Bridgelux |
3,962 | - |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 3511lm (Typ) | 1.05A | 85°C | 28.8V | 116 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
BXRC-40G1000-B-02LED ARRAY 1000LM NEUTRAL WHITE Bridgelux |
3,673 | - |
RFQ |
Ficha técnica |
Tray | Vero® 10 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Starboard | - | 350mA | 85°C | 25.7V | - | 700mA | 90 | 120° | With Connector | 20.00mm Dia | 1.90mm | 9.90mm Dia |
|
|
BXRC-40G10K0-L-02LED ARRAY 10000LM NEUTRAL WHITE Bridgelux |
2,482 | - |
RFQ |
Ficha técnica |
Tray | Vero® 29 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 9060lm (Typ) | 2.1A | 25°C | 38.6V | 112 lm/W | 4.2A | 90 | 120° | With Connector | 49.20mm Dia | 1.90mm | 29.20mm Dia |
|
|
BXRC-40G2000-C-02LED ARRAY 2000LM NEUTRAL WHITE Bridgelux |
3,390 | - |
RFQ |
Ficha técnica |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 1810lm (Typ) | 500mA | 25°C | 32.5V | 111 lm/W | 1.05A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia |
|
|
BXRC-40G2000-C-Z2LED ARRAY 2000LM NEUTRAL WHITE Bridgelux |
3,505 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 1575lm (Typ) | 500mA | 85°C | 31.5V | 100 lm/W | 1.05A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-40G2000-C-Z3LED ARRAY 2000LM NEUTRAL WHITE Bridgelux |
3,355 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 1575lm (Typ) | 500mA | 85°C | 31.5V | 100 lm/W | 1.05A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-40G4000-F-02LED ARRAY 4000LM NEUTRAL WHITE Bridgelux |
2,259 | - |
RFQ |
Ficha técnica |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 3515lm (Typ) | 1.05A | 25°C | 29.5V | 113 lm/W | 2.1A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia |
|
|
BXRC-40G4000-F-Z2LED ARRAY 4000LM NEUTRAL WHITE Bridgelux |
3,230 | - |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 3058lm (Typ) | 1.05A | 85°C | 28.8V | 101 lm/W | 2.1A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-40G4000-F-Z3LED ARRAY 4000LM NEUTRAL WHITE Bridgelux |
3,374 | - |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 3058lm (Typ) | 1.05A | 85°C | 28.8V | 101 lm/W | 2.1A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-50C2000-C-Z4LED ARRAY 2000LM COOL WHITE Bridgelux |
3,179 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Round | 2037lm (Typ) | 500mA | 85°C | 31.3V | 130 lm/W | 1.05A | 70 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-50C4000-F-Z4LED ARRAY 4000LM COOL WHITE Bridgelux |
3,775 | - |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Round | 3898lm (Typ) | 1.05A | 85°C | 28.6V | 130 lm/W | 2.1A | 70 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-50E2000-C-Z4LED ARRAY 2000LM COOL WHITE Bridgelux |
3,337 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Round | 1936lm (Typ) | 500mA | 85°C | 31.3V | 124 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-50E4000-F-Z4LED ARRAY 4000LM COOL WHITE Bridgelux |
3,361 | - |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Round | 3696lm (Typ) | 1.05A | 85°C | 28.6V | 123 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-50G2000-C-Z4LED ARRAY 2000LM COOL WHITE Bridgelux |
2,792 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Round | 1773lm (Typ) | 500mA | 85°C | 31.3V | 113 lm/W | 1.05A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia |
