Iluminación LED - COB, motores, módulos, tiras
| Foto: | Número de parte del fabricante | Disponibilidad | Precio | Cantidad | Ficha técnica | Packaging | Series | ProductStatus | Type | Color | CCT(K) | Wavelength | Configuration | LuminousFlux@Current/Temperature | Current-Test | Temperature-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | CRI(ColorRenderingIndex) | ViewingAngle | Features | Size/Dimension | Height | LightEmittingSurface(LES) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BXRC-27E4000-F-Z3LED ARRAY 4000LM WARM WHITE Bridgelux |
3,359 | - |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K | - | Round | 3150lm (Typ) | 1.05A | 85°C | 27.9V | 108 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
BXRC-27G1000-B-02LED ARRAY 4000LM WARM WHITE Bridgelux |
2,047 | - |
RFQ |
Ficha técnica |
Tray | Vero® 10 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Starboard | 865lm (Typ) | 350mA | 25°C | 26.7V | 93 lm/W | 700mA | 90 | 120° | With Connector | 20.00mm Dia | 1.90mm | 9.90mm Dia |
|
BXRC-27G10K0-L-02LED ARRAY 10000LM WARM WHITE Bridgelux |
2,161 | - |
RFQ |
Ficha técnica |
Tray | Vero® 29 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 7520lm (Typ) | 2.1A | 25°C | 38.6V | 93 lm/W | 4.2A | 90 | 120° | With Connector | 49.20mm Dia | 1.90mm | 29.20mm Dia |
|
BXRC-27G2000-C-02LED ARRAY 2000LM WARM WHITE Bridgelux |
2,661 | - |
RFQ |
Ficha técnica |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 1510lm (Typ) | 500mA | 25°C | 32.5V | 93 lm/W | 1.05A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia |
|
|
BXRC-27G2000-C-Z2LED ARRAY 2000LM WARM WHITE Bridgelux |
2,825 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K | - | Round | 1310lm (Typ) | 500mA | 85°C | 30.8V | 85 lm/W | 1.05A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-27G2000-C-Z3LED ARRAY 2000LM WARM WHITE Bridgelux |
2,139 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K | - | Round | 1310lm (Typ) | 500mA | 85°C | 30.8V | 85 lm/W | 1.05A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-27G4000-F-02LED ARRAY 4000LM WARM WHITE Bridgelux |
2,222 | - |
RFQ |
Ficha técnica |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 2920lm (Typ) | 1.05A | 25°C | 29.5V | 94 lm/W | 2.1A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia |
|
|
BXRC-27G4000-F-Z2LED ARRAY 4000LM WARM WHITE Bridgelux |
2,691 | - |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K | - | Round | 2530lm (Typ) | 1.05A | 85°C | 27.9V | 86 lm/W | 2.1A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-27G4000-F-Z3LED ARRAY 4000LM WARM WHITE Bridgelux |
2,791 | - |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K | - | Round | 2530lm (Typ) | 1.05A | 85°C | 27.9V | 86 lm/W | 2.1A | 90 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-27H1000-B-02LED ARRAY 1000LM WARM WHITE Bridgelux |
3,880 | - |
RFQ |
Ficha técnica |
Tray | Décor Series™ Ultra Vero® 10 | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Starboard | 574lm (Typ) | 350mA | 85°C | 25.8V | 64 lm/W | 700mA | 97 | 120° | With Connector | 20.00mm Dia | 1.90mm | 9.90mm Dia |
|
BXRC-27H2000-C-02LED ARRAY 2000LM WARM WHITE Bridgelux |
3,027 | - |
RFQ |
Ficha técnica |
Tray | Décor Series™ Ultra Vero® 13 | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 992lm (Typ) | 500mA | 85°C | 31.5V | 63 lm/W | 1.05A | 97 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia |
|
|
BXRC-27H4000-F-02LED ARRAY 4000LM WARM WHITE Bridgelux |
3,496 | - |
RFQ |
Ficha técnica |
Tray | Décor Series™ Ultra Vero® 18 | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 1919lm (Typ) | 1.05A | 85°C | 28.8V | 63 lm/W | 2.1A | 97 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia |
|
|
BXRC-30A1001-B-03LED ARRAY 1000LM WARM WHITE Bridgelux |
2,400 | - |
RFQ |
Tray | Décor Series™ Class A Vero® 10 | Obsolete | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Starboard | 728lm (Typ) | 350mA | 85°C | 25.5V | 82 lm/W | 700mA | 93 | 120° | With Connector | 20.00mm Dia | 1.90mm | 9.90mm Dia | |
|
|
BXRC-30A10K0-L-03LED ARRAY 10000LM WARM WHITE Bridgelux |
3,510 | - |
RFQ |
Tray | - | Obsolete | - | White, Warm | 3000K 3-Step MacAdam Ellipse | - | - | - | - | - | - | - | - | - | - | - | 49.20mm Dia | 1.90mm | - | |
|
|
BXRC-30E1000-B-02LED ARRAY 1000LM WARM WHITE Bridgelux |
2,349 | - |
RFQ |
Ficha técnica |
Tray | Vero® 10 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Starboard | 1120lm (Typ) | 350mA | 25°C | 26.7V | 120 lm/W | 700mA | 80 | 120° | With Connector | 20.00mm Dia | 1.90mm | 9.90mm Dia |
|
|
BXRC-30E10K0-L-02LED ARRAY 10000LM WARM WHITE Bridgelux |
3,215 | - |
RFQ |
Ficha técnica |
Tray | Vero® 29 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Round | 9740lm (Typ) | 2.1A | 25°C | 38.6V | 120 lm/W | 4.2A | 80 | 120° | With Connector | 49.20mm Dia | 1.90mm | 29.20mm Dia |
|
|
BXRC-30E2000-C-02LED ARRAY 2000LM WARM WHITE Bridgelux |
3,028 | - |
RFQ |
Ficha técnica |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Round | 1950lm (Typ) | 500mA | 25°C | 32.5V | 120 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia |
|
|
BXRC-30E2000-C-Z2LED ARRAY 2000LM WARM WHITE Bridgelux |
3,497 | - |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K | - | Round | 1910lm (Typ) | 500mA | 85°C | 31.3V | 122 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-30G1000-B-02LED ARRAY 1000LM WARM WHITE Bridgelux |
2,399 | - |
RFQ |
Ficha técnica |
Tray | Vero® 10 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Starboard | 915lm (Typ) | 350mA | 25°C | 26.7V | 98 lm/W | 700mA | 90 | 120° | With Connector | 20.00mm Dia | 1.90mm | 9.90mm Dia |
|
|
BXRC-30G10K0-L-02LED ARRAY 10000LM WARM WHITE Bridgelux |
3,504 | - |
RFQ |
Ficha técnica |
Tray | Vero® 29 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Round | 7960lm (Typ) | 2.1A | 25°C | 38.6V | 98 lm/W | 4.2A | 90 | 120° | With Connector | 49.20mm Dia | 1.90mm | 29.20mm Dia |
