Iluminación LED - COB, motores, módulos, tiras
| Foto: | Número de parte del fabricante | Disponibilidad | Precio | Cantidad | Ficha técnica | Packaging | Series | ProductStatus | Type | Color | CCT(K) | Wavelength | Configuration | LuminousFlux@Current/Temperature | Current-Test | Temperature-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | CRI(ColorRenderingIndex) | ViewingAngle | Features | Size/Dimension | Height | LightEmittingSurface(LES) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CLU048-1818C4-273M2K1COB LED 2700K 80CRI Citizen |
3,849 | - |
RFQ |
Ficha técnica |
Tray | CLU048 | Active | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 11367lm (Typ) | 1.62A | 85°C | 52V | 135 lm/W | 4.14A | 80 | - | - | 28.00mm L x 28.00mm W | 1.40mm | 22.00mm Dia |
|
|
CLU048-1818C4-403M2K1COB LED 4000K 80CRI Citizen |
2,935 | - |
RFQ |
Ficha técnica |
Tray | CLU048 | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 12249lm (Typ) | 1.62A | 85°C | 52V | 145 lm/W | 4.14A | 80 | - | - | 28.00mm L x 28.00mm W | 1.40mm | 22.00mm Dia |
|
|
CLU048-1818C4-303M2K1COB LED 3000K 80CRI Citizen |
2,988 | - |
RFQ |
Ficha técnica |
Tray | CLU048 | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 11881lm (Typ) | 1.62A | 85°C | 52V | 141 lm/W | 4.14A | 80 | - | - | 28.00mm L x 28.00mm W | 1.40mm | 22.00mm Dia |
|
|
CLU048-1818C4-403H5K2COB LED 4000K 90CRI Citizen |
3,064 | - |
RFQ |
Ficha técnica |
Tray | CLU048 | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 10108lm (Typ) | 1.62A | 85°C | 52V | 120 lm/W | 4.14A | 90 | - | - | 28.00mm L x 28.00mm W | 1.40mm | 22.00mm Dia |
|
CLU058-1825C4-303M2K1COB LED 3000K 80CRI Citizen |
2,870 | - |
RFQ |
Ficha técnica |
Tray | CLU058 | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 17398lm (Typ) | 2.25A | 85°C | 52V | 149 lm/W | 5.75A | 80 | - | - | 38.00mm L x 38.00mm W | 1.40mm | 32.80mm Dia |
|
|
CLU058-1825C4-50AL7K3COB LED 5000K 70CRI Citizen |
2,233 | - |
RFQ |
Ficha técnica |
Tray | CLU058 | Active | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 19274lm (Typ) | 2.25A | 85°C | 52V | 165 lm/W | 5.75A | 70 | - | - | 38.00mm L x 38.00mm W | 1.40mm | 32.80mm Dia |
|
CLU701-0304C4-503M2K1COB LED 5000K 80CRI 848LM Citizen |
3,527 | - |
RFQ |
Ficha técnica |
Tray | CLU701 | Active | Chip On Board (COB) | White, Cool | 5000K | - | Square | 848lm (Typ) | 700mA | 85°C | 9.4V | 129 lm/W | 920mA | 80 | - | - | 13.50mm L x 13.50mm W | - | 6.00mm Dia |
|
CLU027-0303C1-303M2G2COB LED 3000K 80CRI 313LM Citizen |
3,705 | - |
RFQ |
Tray | CLU027 | Last Time Buy | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 313lm (Typ) | 270mA | 85°C | 8.7V | 133 lm/W | 690mA | 80 | - | - | 13.50mm L x 13.50mm W | 1.40mm | 6.00mm Dia | |
|
CLU028-1203C4-50AL7K3COB LED 5000K 70CRI Citizen |
3,881 | - |
RFQ |
Ficha técnica |
Tray | CLU028 | Active | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 1498lm (Typ) | 270mA | 85°C | 34.6V | 160 lm/W | 690mA | 70 | - | - | 13.50mm L x 13.50mm W | 1.40mm | 9.80mm Dia |
|
CLU024-1204B8-42GV1F6COB LED VIVID WHITE 1260LM Citizen |
2,640 | - |
RFQ |
Ficha técnica |
Tray | CLU024 | Last Time Buy | Chip On Board (COB) | - | - | - | Square | 1329lm (Typ) | 360mA | 25°C | 35.7V | 103 lm/W | 720mA | 94 (Typ) | - | - | 13.50mm L x 13.50mm W | 1.40mm | 9.80mm Dia |
|
CLU036-1206C1-303M2G2COB LED 3000K 80CRI 2592LM Citizen |
3,759 | - |
RFQ |
Ficha técnica |
Tray | CLU036 | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 2592lm (Typ) | 540mA | 85°C | 34.6V | 139 lm/W | 1.38A | 80 | - | - | 19.00mm L x 19.00mm W | 1.40mm | 14.50mm Dia |
|
CLU056-1825C1-303M2G2COB LED 3000K 80CRI 16444LM Citizen |
3,297 | - |
RFQ |
Ficha técnica |
Tray | CLU056 | Last Time Buy | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 16444lm (Typ) | 2.25A | 85°C | 52V | 141 lm/W | 5.75A | 80 | - | - | 38.00mm L x 38.00mm W | 1.40mm | 32.80mm Dia |
|
CLU550-3626C1-403M2G2-B24COB LED 4000K 80CRI 33150LM Citizen |
3,073 | - |
RFQ |
Ficha técnica |
Tray | CLU550 | Last Time Buy | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 33150lm (Typ) | 2.34A | 85°C | 103.9V | 136 lm/W | 4.68A | 80 | - | - | 38.00mm L x 38.00mm W | 1.40mm | 32.80mm Dia |
|
|
CLU550-3626C1-353M2G2-B24COB LED 3500K 80CRI 32500LM Citizen |
3,387 | - |
RFQ |
Ficha técnica |
Tray | CLU550 | Last Time Buy | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 32500lm (Typ) | 2.34A | 85°C | 103.9V | 134 lm/W | 4.68A | 80 | - | - | 38.00mm L x 38.00mm W | 1.40mm | 32.80mm Dia |
|
|
CLU550-3626C1-503M2G2-B24COB LED 5000K 80CRI 33800LM Citizen |
2,466 | - |
RFQ |
Ficha técnica |
Tray | CLU550 | Last Time Buy | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 33800lm (Typ) | 2.34A | 85°C | 103.9V | 139 lm/W | 4.68A | 80 | - | - | 38.00mm L x 38.00mm W | 1.40mm | 32.80mm Dia |
|
CLU701-0303C4-273H5K2COB LED 2700K 90CRI 480LM Citizen |
3,651 | - |
RFQ |
Ficha técnica |
Tray | CLU701 | Active | Chip On Board (COB) | White, Warm | 2700K | - | Square | 480lm (Typ) | 525mA | 85°C | 9.4V | 97 lm/W | 690mA | 90 | - | - | 13.50mm L x 13.50mm W | - | 6.00mm Dia |
|
|
CLU701-0304C4-303M2K1COB LED 3000K 80CRI 809LM Citizen |
2,512 | - |
RFQ |
Ficha técnica |
Tray | CLU701 | Active | Chip On Board (COB) | White, Warm | 3000K | - | Square | 809lm (Typ) | 700mA | 85°C | 9.4V | 123 lm/W | 920mA | 80 | - | - | 13.50mm L x 13.50mm W | - | 6.00mm Dia |
|
|
CLU701-0304C4-273M2K1COB LED 2700K 80CRI 775LM Citizen |
3,251 | - |
RFQ |
Ficha técnica |
Tray | CLU701 | Active | Chip On Board (COB) | White, Warm | 2700K | - | Square | 775lm (Typ) | 700mA | 85°C | 9.4V | 118 lm/W | 920mA | 80 | - | - | 13.50mm L x 13.50mm W | - | 6.00mm Dia |
|
|
CLU701-0303C4-303H5K2COB LED 3000K 90CRI 502LM Citizen |
3,238 | - |
RFQ |
Ficha técnica |
Tray | CLU701 | Active | Chip On Board (COB) | White, Warm | 3000K | - | Square | 502lm (Typ) | 525mA | 85°C | 9.4V | 102 lm/W | 690mA | 90 | - | - | 13.50mm L x 13.50mm W | - | 6.00mm Dia |
|
|
CLU028-1204C4-403H5K2COB LED 4000K 90CRI Citizen |
2,540 | - |
RFQ |
Ficha técnica |
Tray | CLU028 | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 1507lm (Typ) | 360mA | 85°C | 34.6V | 121 lm/W | 920mA | 90 | - | - | 13.50mm L x 13.50mm W | 1.40mm | 9.80mm Dia |
