Transformadores de audio
| Foto: | Número de parte del fabricante | Disponibilidad | Precio | Cantidad | Ficha técnica | Packaging | Series | ProductStatus | TurnsRatio-Primary:Secondary | Impedance-Primary(Ohms) | Impedance-Secondary(Ohms) | DCResistance(DCR)-Primary | DCResistance(DCR)-Secondary | TransformerType | FrequencyRange | FrequencyResponse | Voltage-Isolation | InsertionLoss | ReturnLoss | PowerLevel | OperatingTemperature | ApprovalAgency | MountingType | Size/Dimension | Height-Seated(Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
141DTRANSFORMER AUDIO 3KCT/1KCT IMP Hammond Manufacturing |
2,707 | - |
RFQ |
Ficha técnica |
Bulk | 141 | Active | - | 3kCT | 1kCT | 120Ohm | 51Ohm | Low Profile, Open Type | 200Hz ~ 15kHz | ±2dB | - | - | - | 150mW | - | - | Through Hole | 0.780 L x 0.660 W (19.81mm x 16.76mm) | 0.460 (11.68mm) |
|
104KTRANSFORMER AUDIO 20000/1000CT Hammond Manufacturing |
2,988 | - |
RFQ |
Ficha técnica |
Bulk | 104 | Active | - | 20k | 1kCT | 790Ohm | 125Ohm | Miniature Epoxy Potted | 200Hz | -1dB | 200V | 1dB | - | 35mW | - | - | Through Hole | 0.860 L x 0.710 W (21.84mm x 18.03mm) | 0.750 (19.05mm) |
|
106GTRANSFORMER AUDIO 4000/600CT Hammond Manufacturing |
2,404 | - |
RFQ |
Ficha técnica |
Bulk | 106 | Active | - | 4k | 600CT | 340Ohm | 24Ohm | Miniature Epoxy Potted | 215Hz | -1dB | 200V | 1dB | - | 150mW | - | - | Through Hole | 1.080 L x 0.880 W (27.43mm x 22.35mm) | 0.950 (24.13mm) |
|
|
106MTRANSFORMER AUDIO 20000/2000CT Hammond Manufacturing |
2,398 | - |
RFQ |
Ficha técnica |
Bulk | 106 | Active | - | 20k | 2kCT | 1.18kOhm | 89Ohm | Miniature Epoxy Potted | 215Hz | -1dB | 200V | 1dB | - | 150mW | - | - | Through Hole | 1.080 L x 0.880 W (27.43mm x 22.35mm) | 0.950 (24.13mm) |
|
117E8TRANSF LINE MATCHING 8W 3.2OHM Hammond Manufacturing |
2,779 | - |
RFQ |
Ficha técnica |
Bulk | 117 | Active | - | 3.2 | 70V | - | - | Sound Distribution | 100Hz ~ 9kHz | 1dB | - | 2dB | - | 8W | - | - | Chassis Mount | 3.250 L x 1.750 W (82.55mm x 44.45mm) | 2.000 (50.80mm) |
|
|
117J8TRANSF LINE MATCHING 8W 3.2 OHM Hammond Manufacturing |
3,178 | - |
RFQ |
Ficha técnica |
Bulk | 117 | Active | - | 3.2 | 25V | - | - | Sound Distribution | 100Hz ~ 9kHz | 1dB | - | 2dB | - | 8W | - | - | Chassis Mount | 3.250 L x 1.750 W (82.55mm x 44.45mm) | 2.000 (50.80mm) |
|
|
106WTRANSFORMER AUDIO 500CT/3.2 Hammond Manufacturing |
3,361 | - |
RFQ |
Ficha técnica |
Bulk | 106 | Active | - | 500CT | 3.2 | 26Ohm | 300mOhm | Miniature Epoxy Potted | 170Hz | -1dB | 200V | 1dB | - | 1.5W | - | - | Through Hole | 1.080 L x 0.880 W (27.43mm x 22.35mm) | 0.950 (24.13mm) |
|
143DTRANSFORMER AUDIO 200K/1K IMPED Hammond Manufacturing |
2,392 | - |
RFQ |
Ficha técnica |
Bulk | 143 | Active | - | 200k | 1k | 4.5kOhm | 30Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 25mW | - | - | Chassis Mount | 1.000 L x 0.690 W (25.40mm x 17.53mm) | 0.690 (17.53mm) |
|
|
143JTRANSFORMER AUDIO 3K/1KCT IMPED Hammond Manufacturing |
3,467 | - |
RFQ |
Ficha técnica |
Bulk | 143 | Active | - | 3k | 1kCT | 265Ohm | 53Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000 L x 0.690 W (25.40mm x 17.53mm) | 0.690 (17.53mm) |
|
|
143HTRANSFORMER AUDIO 1500/500CT IMP Hammond Manufacturing |
3,252 | - |
RFQ |
Ficha técnica |
Bulk | 143 | Active | - | 1.5k | 500CT | 111Ohm | 24Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000 L x 0.690 W (25.40mm x 17.53mm) | 0.690 (17.53mm) |
|
|
143RTRANSFORMER AUDIO 25K/600CT IMP Hammond Manufacturing |
3,859 | - |
RFQ |
Ficha técnica |
Bulk | 143 | Active | - | 25k | 600CT | 1.89kOhm | 25Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000 L x 0.690 W (25.40mm x 17.53mm) | 0.690 (17.53mm) |
|
|
143BTRANSFORMER AUDIO 3.2/4K IMPED Hammond Manufacturing |
3,541 | - |
RFQ |
Ficha técnica |
Bulk | 143 | Active | - | 3.2 | 4k | 400mOhm | 245Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 15mW | - | - | Chassis Mount | 1.000 L x 0.690 W (25.40mm x 17.53mm) | 0.690 (17.53mm) |
|
|
143NTRANSFORMER AUDIO 10K/2KCT IMPED Hammond Manufacturing |
2,129 | - |
RFQ |
Ficha técnica |
Bulk | 143 | Active | - | 10k | 2kCT | 720Ohm | 89Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000 L x 0.690 W (25.40mm x 17.53mm) | 0.690 (17.53mm) |
|
|
143LTRANSFORMER AUDIO 10K/200CT IMP Hammond Manufacturing |
2,019 | - |
RFQ |
Ficha técnica |
Bulk | 143 | Active | - | 10k | 200CT | 720Ohm | 9Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000 L x 0.690 W (25.40mm x 17.53mm) | 0.690 (17.53mm) |
|
PWDA13083AUD XFMR 9KCT/5K:500:100 CHAS MT Hammond Manufacturing |
3,103 | - |
RFQ |
Ficha técnica |
Bulk | Peter W. Dahl Design, Hallicrafters SX-28 | Active | - | 9kCT | 5k, 500, 100 | - | - | - | - | - | - | - | - | - | - | - | Chassis Mount | 3.250 L x 1.750 W (82.55mm x 44.45mm) | 2.058 (52.27mm) |
|
560JTRANS AUDIO 150/600 1.2K/4.8KIMP Hammond Manufacturing |
3,471 | - |
RFQ |
Ficha técnica |
Bulk | 560 | Active | - | 600, 150/150 | 4.8k, 1.2k/1.2k | - | - | Broadcast Quality | 30Hz ~ 30kHz | ±1dB | - | 1dB Max | - | - | - | - | Through Hole | 1.330 L x 1.640 W (33.78mm x 41.66mm) | 0.850 (21.59mm) |
|
140MEXTRANS AUDIO STU GR 100K/1.5K IMP Hammond Manufacturing |
3,272 | - |
RFQ |
Ficha técnica |
Bulk | 140EX | Active | 8.13:1 | 100k | 1.5k | 5.43kOhm | 159Ohm | - | 20Hz ~ 20kHz | ±1dB | 500Vrms | 1.2dB Typ | 30dB Typ | 10dB | - | - | Chassis Mount | 1.250 Dia (31.75mm) | 1.000 (25.40mm) |
|
|
140NEXTRANSFORMER AUDIO Hammond Manufacturing |
3,968 | - |
RFQ |
Ficha técnica |
Bulk | 140EX | Active | 1:5.47 | 50 | 1.5k | 5.3Ohm | 116.5Ohm | - | 20Hz ~ 20kHz | ±1dB | 500Vrms | 0.9dB Typ | 28dB Typ | 10dB | - | - | Chassis Mount | 1.250 Dia (31.75mm) | 1.000 (25.40mm) |
|
|
PWDM13226XFRMR VIKING II MOD 795VCT 500VA Hammond Manufacturing |
2,625 | - |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
140PEXTRANSFORMER AUDIO Hammond Manufacturing |
2,295 | - |
RFQ |
Ficha técnica |
Bulk | 140EX | Active | 1:1, 1:2, 1:4 | 600, 150/150 | 2.4k, 600/600 | 58Ohm | 190Ohm | - | 20Hz ~ 20kHz | ±1dB | 500Vrms | 0.8dB Typ | 30dB Typ | 10dB | - | - | Chassis Mount | 1.250 Dia (31.75mm) | 1.000 (25.40mm) |
