Condensadores electrolíticos de aluminio
| Foto: | Número de parte del fabricante | Disponibilidad | Precio | Cantidad | Ficha técnica | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
UWS1A471MCL1GSCAP ALUM 470UF 20% 10V SMD Nichicon |
2,701 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 470 µF | ±20% | 10 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 290 mA @ 120 Hz | 377 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.394 (10.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
UWS1A681MCL1GSCAP ALUM 680UF 20% 10V SMD Nichicon |
2,155 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 680 µF | ±20% | 10 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 374 mA @ 120 Hz | 486.2 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
UWS1C101MCL1GSCAP ALUM 100UF 20% 16V SMD Nichicon |
2,670 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 100 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 125 mA @ 120 Hz | 162.5 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.244 (6.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
UWS1C151MCL1GSCAP ALUM 150UF 20% 16V SMD Nichicon |
2,884 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 150 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 151 mA @ 120 Hz | 196.3 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.303 (7.70mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
UWS1C221MCL1GSCAP ALUM 220UF 20% 16V SMD Nichicon |
2,410 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 220 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 215 mA @ 120 Hz | 344 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.394 (10.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
UWS1C331MCL1GSCAP ALUM 330UF 20% 16V SMD Nichicon |
3,400 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 330 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 270 mA @ 120 Hz | 351 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.394 (10.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
UWS1C681MCL1GSCAP ALUM 680UF 20% 16V SMD Nichicon |
3,771 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 680 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 396 mA @ 120 Hz | 514.8 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
UWS1E151MCL1GSCAP ALUM 150UF 20% 25V SMD Nichicon |
2,652 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 150 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 192 mA @ 120 Hz | 249.6 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.394 (10.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
UWS1E221MCL1GSCAP ALUM 220UF 20% 25V SMD Nichicon |
3,950 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 220 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 250 mA @ 120 Hz | 325 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
UWS1E331MCL1GSCAP ALUM 330UF 20% 25V SMD Nichicon |
3,791 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 330 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 305 mA @ 120 Hz | 396.5 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
UWS1E470MCL1GSCAP ALUM 47UF 20% 25V SMD Nichicon |
3,106 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 47 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 65 mA @ 120 Hz | 108.55 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.228 (5.80mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
UWS1E471MCL1GSCAP ALUM 470UF 20% 25V SMD Nichicon |
2,155 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 470 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 393 mA @ 120 Hz | 510.9 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
UWS1H101MCL1GSCAP ALUM 100UF 20% 50V SMD Nichicon |
2,928 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 100 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 195 mA @ 120 Hz | 253.5 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
UWS1H151MCL1GSCAP ALUM 150UF 20% 50V SMD Nichicon |
3,257 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 150 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 238 mA @ 120 Hz | 309.4 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
UWS1H220MCL1GSCAP ALUM 22UF 20% 50V SMD Nichicon |
3,500 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 22 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 45 mA @ 120 Hz | 75.15 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.228 (5.80mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
UWS1H330MCL1GSCAP ALUM 33UF 20% 50V SMD Nichicon |
3,727 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 33 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 95 mA @ 120 Hz | 158.65 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.244 (6.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
UWS1V151MCL1GSCAP ALUM 150UF 20% 35V SMD Nichicon |
2,137 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 150 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 214 mA @ 120 Hz | 278.2 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.394 (10.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
UWS1V221MCL1GSCAP ALUM 220UF 20% 35V SMD Nichicon |
3,505 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 220 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 265 mA @ 120 Hz | 344.5 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
UWS1V330MCL1GSCAP ALUM 33UF 20% 35V SMD Nichicon |
3,112 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 33 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 55 mA @ 120 Hz | 91.85 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.228 (5.80mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
UWS1V331MCL1GSCAP ALUM 330UF 20% 35V SMD Nichicon |
3,046 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | UWS | Obsolete | 330 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | High Temperature Reflow | 324 mA @ 120 Hz | 421.2 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
