Condensadores electrolíticos de aluminio
| Foto: | Número de parte del fabricante | Disponibilidad | Precio | Cantidad | Ficha técnica | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEE-HBE100UARCAP ALUM 10UF 20% 25V SMD Panasonic Electronic Components |
4,221 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | HB | Active | 10 µF | ±20% | 25 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 28 mA @ 120 Hz | 47.6 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.228 (5.80mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
ECA-2CHG4R7BCAP ALUM 4.7UF 20% 160V RADIAL Panasonic Electronic Components |
2,103 | - |
RFQ |
Ficha técnica |
Cut Tape (CT),Tape & Box (TB) | NHG-A | Active | 4.7 µF | ±20% | 160 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 43 mA @ 120 Hz | 64.5 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.248 Dia (6.30mm) | 0.480 (12.20mm) | - | Through Hole |
|
EEU-FC1H470BCAP ALUM 47UF 20% 50V RADIAL Panasonic Electronic Components |
8,343 | - |
RFQ |
Ficha técnica |
Cut Tape (CT),Tape & Box (TB) | FC | Active | 47 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 169 mA @ 120 Hz | 260 mA @ 100 kHz | 600 mOhms | 0.197 (5.00mm) | 0.248 Dia (6.30mm) | 0.579 (14.70mm) | - | Through Hole |
|
|
EEU-FC1C101HCAP ALUM 100UF 20% 16V RADIAL Panasonic Electronic Components |
3,815 | - |
RFQ |
Ficha técnica |
Cut Tape (CT),Tape & Box (TB) | FC | Active | 100 µF | ±20% | 16 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 188.5 mA @ 120 Hz | 290 mA @ 100 kHz | 350 mOhms | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.480 (12.20mm) | - | Through Hole |
|
EEE-1AA101WARCAP ALUM 100UF 20% 10V SMD Panasonic Electronic Components |
3,900 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | S | Active | 100 µF | ±20% | 10 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 50 mA @ 120 Hz | 85 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.213 (5.40mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
EEU-FS1C511BCAP ALUM 510UF 20% 16V RADIAL Panasonic Electronic Components |
2,556 | - |
RFQ |
Ficha técnica |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 510 µF | ±20% | 16 V | - | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 712.5 mA @ 120 Hz | 950 mA @ 100 kHz | 56 mOhms | 0.197 (5.00mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
EEE-FN1H100URCAP ALUM 10UF 20% 50V SMD Panasonic Electronic Components |
6,126 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 10 µF | ±20% | 50 V | 3.5Ohm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 39 mA @ 120 Hz | 60 mA @ 100 kHz | - | - | 0.157 Dia (4.00mm) | 0.240 (6.10mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
EEE-FN1A470URCAP ALUM 47UF 20% 10V SMD Panasonic Electronic Components |
2,950 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 47 µF | ±20% | 10 V | 1.35Ohm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 58.5 mA @ 120 Hz | 90 mA @ 100 kHz | - | - | 0.157 Dia (4.00mm) | 0.240 (6.10mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
EEE-HAJ101WARCAP ALUM 100UF 20% 6.3V SMD Panasonic Electronic Components |
22,920 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | HA | Active | 100 µF | ±20% | 6.3 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 47 mA @ 120 Hz | 79.9 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.213 (5.40mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
EEE-FPC220UARCAP ALUM 22UF 20% 16V SMD Panasonic Electronic Components |
35,800 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | FP | Active | 22 µF | ±20% | 16 V | 850mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 104 mA @ 120 Hz | 160 mA @ 100 kHz | - | - | 0.157 Dia (4.00mm) | 0.228 (5.80mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
ECE-A1AN101XBCAP ALUM 100UF 20% 10V RADIAL Panasonic Electronic Components |
67,633 | - |
RFQ |
Ficha técnica |
Cut Tape (CT),Tape & Box (TB) | SU | Active | 100 µF | ±20% | 10 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Bi-Polar | - | General Purpose | 130 mA @ 120 Hz | 221 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.248 Dia (6.30mm) | 0.480 (12.20mm) | - | Through Hole |
|
EEE-FK1H330PCAP ALUM 33UF 20% 50V SMD Panasonic Electronic Components |
3,731 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | FK | Active | 33 µF | ±20% | 50 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 146.3 mA @ 120 Hz | 195 mA @ 100 kHz | 680 mOhms | - | 0.315 Dia (8.00mm) | 0.256 (6.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEE-FT1C470ARCAP ALUM 47UF 20% 16V SMD Panasonic Electronic Components |
65,364 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | FT | Active | 47 µF | ±20% | 16 V | 850mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 104 mA @ 120 Hz | 160 mA @ 100 kHz | - | - | 0.157 Dia (4.00mm) | 0.240 (6.10mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
EEE-FT1E220ARCAP ALUM 22UF 20% 25V SMD Panasonic Electronic Components |
4,830 | - |
RFQ |
Ficha técnica |
Tape & Reel (TR),Cut Tape (CT) | FT | Active | 22 µF | ±20% | 25 V | 850mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 104 mA @ 120 Hz | 160 mA @ 100 kHz | - | - | 0.157 Dia (4.00mm) | 0.240 (6.10mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
EEU-FC1V101BCAP ALUM 100UF 20% 35V RADIAL Panasonic Electronic Components |
2,573 | - |
RFQ |
Ficha técnica |
Cut Tape (CT),Tape & Box (TB) | FC | Active | 100 µF | ±20% | 35 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 360.8 mA @ 120 Hz | 555 mA @ 100 kHz | 117 mOhms | 0.197 (5.00mm) | 0.315 Dia (8.00mm) | 0.650 (16.50mm) | - | Through Hole |
|
ECA-1AM101CAP ALUM 100UF 20% 10V RADIAL Panasonic Electronic Components |
29,390 | - |
RFQ |
Ficha técnica |
Bulk | M-A | Active | 100 µF | ±20% | 10 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | 255 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
|
ECA-1CM330CAP ALUM 33UF 20% 16V RADIAL Panasonic Electronic Components |
10,135 | - |
RFQ |
Ficha técnica |
Bulk | M-A | Active | 33 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 110 mA @ 120 Hz | 187 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
ECA-1HHG101BCAP ALUM 100UF 20% 50V RADIAL Panasonic Electronic Components |
5,079 | - |
RFQ |
Ficha técnica |
Cut Tape (CT),Tape & Box (TB) | NHG-A | Active | 100 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 180 mA @ 120 Hz | 270 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.315 Dia (8.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
EEU-FC1V221BCAP ALUM 220UF 20% 35V RADIAL Panasonic Electronic Components |
408 | - |
RFQ |
Ficha técnica |
Cut Tape (CT),Tape & Box (TB) | FC | Active | 220 µF | ±20% | 35 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 490.8 mA @ 120 Hz | 755 mA @ 100 kHz | 90 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.531 (13.50mm) | - | Through Hole |
|
EEA-GA1C101BCAP ALUM 100UF 20% 16V RADIAL Panasonic Electronic Components |
4,253 | - |
RFQ |
Ficha técnica |
Cut Tape (CT),Tape & Box (TB) | GA-A | Active | 100 µF | ±20% | 16 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 120 mA @ 120 Hz | 186 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.315 Dia (8.00mm) | 0.276 (7.00mm) | - | Through Hole |
